Christini AWD Fat 4" GX Eagle (RockShox 100mm Fork) DEMO
Details
**PHOTOS are different than the spec of this bike**
Please note that the frame color is black and this bike has a RockShox 100mm travel fork - not the rigid fork shown in the photos.
This is a demo bike that has been ridden a few times. It's still a part of our rental fleet but if you want it - it's yours! Try before you buy!
Taken from a design that first started with an successful idita bike race, the AWD 4? Fat gets all the benefits of AWD with a nimble 4? split frame design and a SRAM GX build kit. The bike can slice and dice the trails but climb like a mule. The proprietary AWD system integrates cleanly into this 4? split frame Fat bike without the use of a Universal joint to transfer the power to the front of the bike. This bike will help you climb hills you never thought possible with a bike.
CHRISTINI AWD System
– Handelbar mounted AWD shift on the fly engagement switch
– Spiral-Drive 7075 aluminum bevel and pinion gears
– 7075 aluminum interlocking clutch
– Tubular aluminum drive shafts
– Stainless sealed cartridge bearings
– Total AWD system weight is 2.3 lbs
Specs
| Frame | 6061 T6 Aluminum with integrated direct AWD system |
|---|---|
| Fork | RockShox 100mm Travel |
| Headset | CHRISTINI integrated headset with sealed bearings. |
| Rims/Wheels | Sun Ringle Mulefut 80m Rim 27.5 Tubeless setup |
| Hubs | (F): CHRISTINI AWD one way clutching, (R): 27.5 Sun Ringle SRC-177mm thru-axle XD Drive |
| Spokes | Wheelsmith DB black |
| Tires | Vee Rubber Crown Gem 27.5 x 3.8 |
| Crankset | SRAM GX Eagle DUB Crankset – 170mm |
| Chainwheel | SRAM 30 Tooth X-Sync |
| Bottom Bracket | SRAM DUB 100mm Bottom Bracket |
| Chain | SRAM GX Eagle 12 Speed Chain |
| Rear Derailleur | SRAM GX Eagle 12 Speed Rear Derailleur |
| Rear Cogs | SRAM XG-1275 GX Eagle Cassette |
| Shifters | SRAM GX Eagle 12 Speed Trigger Shifter |
| Handlebars | RaceFace Aeffect 35mm Riser |
| Tape/Grips | Ergon GP1 |
| Stem | RaceFace Aeffect 35mm 60mm |
| Brake Levers | SRAM Level Hydraulic (or AVID FR-7 Cable) |
| Brakes | SRAM Level Hydraulic (or AVID BB7 Cable) w/ SRAM Centerline 180mm Rotors |
| Pedals | Race Face Chester composite platform |
| Saddle | WTB Speed Pro Gel |
| Seat Post | RaceFace Turbine 31.6 |
| Color(s) | Black |
| Weight | 33lbs (size Medium) |
* Subject to change without notice.
Videos
How It Works
Cross Section Internals
Part Numbers
| Option | MPN | Store SKU |
|---|---|---|
| Black / Medium | 2022christinifat4gxrs100blackmd | 210000012269 |
